The rugged terrain of hydropower project sites often presents engineers with complex geological conditions—fractured rock masses, loose overburden, and water ingress. On one such slope stabilization project for a major hydropower station, traditional solid threaded bars proved inadequate due to poor bond strength in fractured dolomite and slow installation times. SupAnchor® stepped in with its advanced Grade 75 self-drilling hollow anchor bars, part of a comprehensive self drilling anchor system, delivering a cost-effective and technically superior solution that ensured long-term slope safety.
Facing a 65-meter-high cut slope with heavily jointed limestone and intermittent clay seams, the project required an anchoring method that could be installed rapidly through caving ground while providing immediate load-bearing capacity. SupAnchor’s Grade 75 self drilling anchor bolt solved these challenges by combining drilling, grouting, and anchoring in one continuous operation, eliminating the need for casing and reducing installation time by over 40% compared to conventional methods.
The core of this success lies in the meticulously engineered Grade 75 hollow bar, manufactured to ASTM A615 standards. Its continuous T-thread profile, with an elevated rib area, enhances mechanical interlock with cement grout, achieving pull-out strengths that often exceed those of ribbed solid bars. The left-hand thread ensures consistent coupling with SupAnchor’s R and T thread systems, allowing easy extension for deep borehole applications.
| Parameter | Value | Significance |
|---|---|---|
| Ultimate Load | 196 kN (44 kips) | Handles high tensile forces in unstable slopes |
| Yield Load | 147 kN (33 kips) | Plastic deformation limit for design safety |
| Elongation | ≥ 6% | Ductility to absorb dynamic loads without brittle failure |
| Weight | 2.6 kg/m (1.75 lbs/ft) | Lightweight yet strong, easing handling and logistics |
| Thread Type | Continuous T-thread (left-hand) | Optimized grout bond and seamless coupling with system components |
During site execution, the drill-and-grout bolt was advanced using standard rotary-percussive rigs with a sacrificial drill bit. Flushing was performed through the hollow core, and cement grout was injected under pressure once the required depth was reached. The corrugated thread profile allowed excellent grout permeation, creating a full-column bond that transformed the bar into a hollow bar anchor with superior skin friction. Post-installation pull-out tests consistently exceeded design loads, validating the system’s reliability even in water-bearing strata.
Grade 75 self drilling anchor bolts are not limited to slope stabilization. In a recent tunneling project through mixed-face conditions in the Alps, the bars served as temporary face support and systematic radial bolts, their rapid installation cycle minimizing stand-still time. In foundation reinforcement for a high-rise building on reclaimed land, the system acted as a geotechnical reinforcement system, transferring tensile loads to deeper competent strata without the need for large-diameter drilled shafts.
The versatility of the self drilling anchor system extends to:
In each case, SupAnchor’s engineering team collaborated closely with contractors to optimize bar lengths, grout mixes, and installation sequences. This collaborative approach, combined with real-time technical support, exemplifies the “Professional, Innovative, Collaborative” ethos that defines the brand.
The global infrastructure boom—from hydroelectric plants in Southeast Asia to metro expansions in Europe—demands anchoring solutions that balance performance with economy. The Grade 75 hollow bar addresses this by reducing steel consumption per meter compared to solid bars of equivalent strength, while eliminating casing costs and accelerating construction schedules. As a leading soil nail system manufacturer and ground anchor bolt factory, SupAnchor fills a gap for projects requiring ASTM-compliant hollow bars with chemical and mechanical properties tailored to geotechnical challenges.
Furthermore, the environmental footprint is minimized: fewer materials, less equipment movement, and reduced grout wastage contribute to greener construction practices. The full-column bonding also ensures long-term corrosion protection without additional sheathing, a critical factor for permanent structures.
Behind every self drilling anchor bolt is a company deeply invested in R&D. SupAnchor holds ISO 9001 and ISO 14001 certifications, and its testing laboratory is equipped for full-scale static and dynamic load testing. Continuous improvement programs refine thread geometries, steel chemistries, and manufacturing tolerances to push the boundaries of what hollow bar anchors can achieve.
With installations in over 30 countries, SupAnchor has become a trusted partner for Tier 1 contractors facing difficult ground. The Grade 75 self drilling anchor system is the latest addition to a product line that includes R and T thread bars, accessories, and drilling rigs—all designed to work seamlessly together, reducing interface risk for project owners.
As infrastructure projects grow bolder and more complex, the need for reliable, adaptable geotechnical reinforcement system solutions will only intensify. SupAnchor’s Grade 75 hollow anchor bars stand ready to meet that demand, anchoring the future with precision and strength.
