In response to growing global demands for safer and more efficient ground support in tunneling and mining, SupAnchor has introduced its SupHulk PM series swell friction bolts. These high-yield rock bolts are engineered to deliver immediate, full-column support in a wide range of geological conditions, providing engineers and contractors with a reliable tool for stabilizing rock masses. As a leading self drilling anchor system manufacturer, SupAnchor leverages decades of expertise to offer solutions that combine rapid installation with long-term performance, addressing the critical needs of infrastructure projects worldwide.
The SupHulk PM series comprises three models—PM12, PM16, and PM24—each tailored to specific load requirements. Unlike traditional point-anchored bolts, these friction bolts form a continuous bond along the entire borehole through controlled inflation. The resulting friction and interlocking mechanism distributes the carrying force evenly, enabling the bolt to absorb rock movements instantly. Key performance parameters are summarized below, showcasing the robust engineering behind this geotechnical reinforcement system.
| Model | Min. Yield Load (kN) | Min. Breaking Load (kN) | Elongation A100mm (%) | Profile Diameter (mm) | Recommended Hole Diameter (mm) | Inflation Pressure (bar) |
|---|---|---|---|---|---|---|
| PM12 | 100 | 110 | ≥10 | 27 | 32-39 | 300 |
| PM16 | 130 | 160 | ≥10 | 36 | 43-52 | 240 |
| PM24 | 200 | 240 | ≥10 | 36 | 43-52 | 300 |
The PM series is characterized by a minimum elongation of 10% (A100mm), ensuring excellent deformability. This is critical in ground conditions prone to shear movements, as the bolt can accommodate significant displacement without failure. The profile diameter, hole diameter, and inflation pressure vary by model to suit different rock types and borehole sizes. For instance, the PM12 uses a 27 mm profile and requires a 32-39 mm hole, while the larger PM16 and PM24 share a 36 mm profile with a hole diameter of 43-52 mm. Inflation pressures range from 240 to 300 bar, with an automatic pump shut-off that guarantees consistent installation quality—a key advantage over manual tensioning methods.
The SupHulk rock bolt is sealed at one end and fitted with a special head bushing for inflation at the other. Once inserted into the borehole, high-pressure water expands the bolt, pressing it against the rock walls. This creates an immediate friction and interlocking bond that provides full-column support along the entire length—an anchorage mechanism that has proven effective in fractured and irregular rock masses. Key practical features of the system include:
These attributes make the SupHulk bolt particularly valuable in environments where ground conditions change rapidly and support must be installed quickly without compromising safety. Operators can perform pull tests at any time to verify performance, adding a layer of quality control that is essential in critical excavations.
SupHulk rock bolts are designed for a wide range of reinforcement applications. In tunneling, they serve as pattern bolts for systematic radial support; the bolting pattern is determined by excavation size and rock mass quality. In mining, common uses include roof bolting and hanging wall bolting, where the ability to install a self drilling anchor bolt rapidly and safely is paramount. With capacity options of 110 kN, 160 kN, and 240 kN, the PM series covers most ground support needs, from low-stress sedimentary formations to harder, fractured rock.
The system's adaptability is further enhanced by its compatibility with standard drilling equipment. Since the bolt itself is not a drill-and-grout bolt but a friction type, installation requires only a pre-drilled hole, reducing complexity. This simplicity has made it a preferred choice in projects where time is critical and immediate support is needed to prevent falls of ground. Whether it's a transit tunnel under a major city or a deep mine shaft, SupHulk friction bolts deliver consistent, high-performance anchorage.
As global infrastructure investment surges—driven by urban transit expansion, renewable energy projects, and deeper mineral extraction—the demand for reliable ground support has never been greater. The geotechnical reinforcement system market increasingly expects solutions that offer not only strength but also installation speed, verification ease, and long-term durability. SupHulk friction bolts meet these demands by providing an efficient alternative to traditional grouted anchors. They eliminate the need for cement or resin, reduce curing time, and can be installed in difficult ground conditions where grout might wash out or fail to bond.
From a project management perspective, the ability to immediately load a bolt after inflation translates into faster cycle times and reduced downtime. This is especially valuable in drill-and-blast operations where rapid re-entry is critical. Furthermore, the friction-based support mechanism can compensate for minor geological variations, making it a robust choice for geologically diverse projects. For contractors seeking a single-source supplier for ground support, SupAnchor’s portfolio—which also includes hollow bar anchor and self drilling anchor system components—simplifies logistics and ensures technical consistency across a project.
Behind the SupHulk series is a company with a proven track record in geotechnical engineering. SupAnchor has earned international recognition as a ground anchor bolt factory that combines R&D-driven innovation with strict quality control. All products are manufactured under ISO-certified processes, and the company continuously invests in testing and field validation. The SupHulk bolt, for example, undergoes rigorous pull-out and fatigue tests to confirm its load-bearing capacity and deformability.
More than a product supplier, SupAnchor partners with engineering firms and contractors to customize solutions for specific site conditions. This collaborative approach, supported by a global network of distributors and technical consultants, ensures that each installation benefits from the latest advancements in rock reinforcement technology. As projects push deeper and encounter more challenging ground, the industry can rely on solutions like the SupHulk PM series—where professional engineering, innovative design, and collaborative spirit converge to raise the bar for safety and performance underground.
