In coastal engineering, chemical plants, and humid underground spaces, corrosion poses a critical threat to structural integrity. Standard carbon steel anchors, even with coatings, often succumb to rust and pitting within years, requiring costly maintenance or replacement. Addressing this challenge, SupAnchor, Asia's leading manufacturer and exporter of self-drilling anchors, has unveiled a stainless steel variant of its renowned self-drilling hollow anchor system. Designed for long-term durability in aggressive environments, this new product retains the core '3-in-1 principle'—integrating a sacrificial drilling rod, injection tube, and reinforcing bar into a single hollow bar—while leveraging stainless steel's inherent corrosion resistance to ensure decades of reliable performance.
The stainless steel self-drilling hollow anchor is a specialized addition to SupAnchor's anti-corrosion portfolio, which already includes hot-dip galvanizing and SupCoating. It follows the same design logic as the company's R thread and T thread series, using a ribbed hollow stainless steel bar as the load-bearing member. This design enables simultaneous drilling and grouting, eliminating the need for separate casing systems—a critical advantage in unconsolidated or cohesive soils where traditional drilling is slow and risky.
For the representative model R32SS/15, the technical specifications demonstrate the system's robust performance:
| Parameter | Value |
|---|---|
| Outside Diameter | 32 mm |
| Internal Diameter | 14 mm |
| Cross Sectional Area | 509 mm² |
| Ultimate Load | ≥405 kN |
| Yield Load | ≥300 kN |
| Weight | 4.00 kg/m |
| Thread Type | ISO 10208 - R32 / Left or Right |
| Steel Type | Stainless Steel (EN standards) |
| Elongation | A100mm ≥6% / Agt ≥5% / A200mm ≥6% |
| Lengths | 2, 3, 4, 5, 6 m |
The rib structure follows an optimized relative rib area (fR = 0.21–0.33) to maximize bonding with grouting materials, while 45° angled rib surfaces reduce splitting forces on surrounding soil or rock—keeping crack widths below 0.1 mm at maximum load. This design ensures that the geotechnical reinforcement system provides both immediate and long-term stability.
Compatibility with standard accessories, such as SW46 series nuts, D42 series couplers, and 200×200×12 mm anchor plates, simplifies installation and logistics for contractors. The stainless steel variant is available in other diameters (25, 38, 51 mm) to match project requirements for load capacity and space constraints, all while maintaining the 3-in-1 functionality.
The stainless steel self-drilling anchor is particularly suited for environments where corrosion resistance is paramount. Key applications include:
In these scenarios, the self drilling anchor bolt reduces installation time by combining drilling and grouting into one operation, while the stainless steel material eliminates the need for post-installation corrosion protection. This translates to lower lifecycle costs and enhanced reliability for critical infrastructure.
SupAnchor’s new stainless steel variant addresses a growing demand in global infrastructure for sustainable, low-maintenance solutions. As a soil nail system manufacturer and ground anchor bolt factory with ISO certifications, SupAnchor has supplied its self drilling anchor system to major projects worldwide, including tunneling, mining, and slope stabilization. The company’s R&D focus on innovation is evident in this product, which extends the service life of anchors in corrosive environments without compromising mechanical performance.
The hollow bar anchor design itself is a hallmark of SupAnchor’s engineering expertise. By integrating drilling, grouting, and reinforcement into a single element, the system reduces equipment needs and speeds up construction—critical in time-sensitive projects. The stainless steel variant further enhances this value by offering a premium solution for projects where corrosion is a primary concern.
With a commitment to professionalism, innovation, and collaboration, SupAnchor continues to set standards in the geotechnical reinforcement industry. The stainless steel self-drilling anchor exemplifies how advanced materials can solve real-world engineering challenges, providing engineers with a reliable tool for building in demanding environments.
