In an era where global infrastructure demands are pushing the limits of geotechnical engineering, projects across Europe and the Americas face significant challenges from unstable soils, high tensile forces, and the need for rapid, reliable construction. SupAnchor, recognized as Asia's leading manufacturer and exporter of self-drilling anchors, has unveiled the Grade 75 Self-Drilling Hollow Anchor, a high-strength variant designed to address these issues. This innovation enhances load-bearing capacity while retaining the core 3-in-1 principle—integrating drilling, grouting, and reinforcement into a single system—thereby improving efficiency and safety in critical applications such as tunnel support, slope stabilization, and deep foundation works.
The Grade 75 self-drilling anchor system leverages high-strength steel to deliver superior performance in geotechnical reinforcement. Key parameters, inferred from SupAnchor's product line, highlight its capabilities for heavy-load scenarios. For instance, the R32 model features an ultimate load of ≥380-420 kN and a yield load of ≥300-340 kN, while the R38 model reaches up to ≥550-600 kN ultimate load, making it ideal for projects requiring robust support against soil pressure and structural deformation. The 3-in-1 design allows simultaneous drilling and grouting, eliminating the need for separate casing and reducing construction time by up to 30% in cohesive or unconsolidated soils. This geotechnical reinforcement system ensures stability with crack widths below 0.1 mm under maximum load, addressing common engineering challenges like settlement risks and inefficient step-by-step methods.
| Parameter | R32 Model | R38 Model |
| Outside Diameter (mm) | 32 | 38 |
| Ultimate Load (kN) | ≥380-420 | ≥550-600 |
| Yield Load (kN) | ≥300-340 | ≥440-480 |
| Weight (kg/m) | 3.2-3.6 | 4.7-5.1 |
| Corrosion Protection | Hot-dip galvanizing, SupCoating | Hot-dip galvanizing, SupCoating |
These specs, combined with standardized thread designs compliant with ISO 10208, enable quick on-site connections and compatibility with accessories like nuts and plates, further enhancing the hollow bar anchor's adaptability. The high-strength material ensures minimal deformation under extreme loads, providing a reliable solution for geotechnical engineers dealing with variable ground conditions.
The Grade 75 self-drilling anchor bolt excels in diverse scenarios, from heavy-duty infrastructure to critical structural support. In Europe, where tunneling projects for railways and highways often encounter soft soils, this drill-and-grout bolt offers a efficient alternative to traditional methods, reducing labor intensity and project delays. Applications include:
Benefits extend beyond technical performance; this self-drilling anchor system promotes cost savings through faster installation and reduced material waste. By addressing soil nail system needs in slope stabilization, it enhances geotechnical safety, preventing failures that could impact urban development and environmental sustainability. The compatibility with anti-corrosion treatments allows use in damp or moderately corrosive settings, broadening its appeal for global infrastructure projects.
SupAnchor's introduction of the Grade 75 anchor underscores its commitment to innovation and collaboration in the geotechnical sector. As the top self-drilling anchor bolt manufacturer in Asia, the company invests heavily in R&D, adhering to international standards like ISO 10208 and ISO 1720 to ensure product reliability. Their global projects, including collaborations in European tunneling and American bridge construction, demonstrate the practical value of this high-strength hollow bar anchor. The professional approach, combined with a focus on sustainable engineering, positions SupAnchor as a key player in advancing geotechnical reinforcement systems worldwide. This product not only meets current market demands but also sets a benchmark for future developments in drill-and-grout technology, fostering safer and more efficient construction practices.
In summary, the Grade 75 Self-Drilling Hollow Anchor represents a significant leap forward for geotechnical engineering, offering a blend of high strength, efficiency, and reliability. SupAnchor's innovative spirit and collaborative ethos ensure that this self-drilling anchor system will play a vital role in shaping resilient infrastructure across the globe.
