In the realm of geotechnical engineering, projects frequently encounter unstable soils, high structural loads, and challenging environmental conditions that demand robust reinforcement solutions. SupAnchor, recognized as Asia's premier manufacturer and exporter of self-drilling anchors, has launched the SupUTS series, a high-performance self-drilling hollow anchor designed to address these complexities. This innovation promises to enhance safety and efficiency in critical infrastructure developments worldwide, from deep tunnel excavations to coastal defense systems.
The SupUTS self-drilling anchor system integrates a ribbed hollow steel bar that serves as a drill rod, grout injection tube, and reinforcement bar in one unit, streamlining construction processes. This 3-in-1 design eliminates the need for separate equipment, reducing time and risks in unconsolidated or cohesive soils. Key parameters highlight its high-strength performance, with ultimate tensile loads ranging from 360 kN to 930 kN across models, ensuring reliability in high-demand scenarios. The anchor's standardized thread design and compatibility with SupAnchor's accessory system facilitate quick installation, while anti-corrosion options—including hot-dip galvanizing, SupCoating, and stainless steel—extend service life in varied environments.
| Model | Outside Diameter (mm) | Ultimate Load (kN) | Yield Load (kN) | Weight (kg/m) | Anchor Plate Size (mm) |
|---|---|---|---|---|---|
| SSTR32/360 | 32 | ≥360 | ≥280 | 3.5-4.0 | 200 x 200 x 12 |
| SSTR38/660 | 38 | ≥660 | ≥520 | 6.3-6.8 | 250 x 250 x 16 |
| SSTR51/930 | 51 | ≥930 | ≥730 | 9.0-9.5 | 300 x 300 x 20 |
This self-drilling anchor bolt system solves engineering challenges by providing high tensile strength and efficient grouting, which minimizes soil disturbance and ensures structural integrity. The hollow bar anchor design allows for simultaneous drilling and grouting, making it ideal for projects where time and safety are critical.
The SupUTS series is tailored for heavy-duty geotechnical reinforcement systems, including:
This geotechnical reinforcement system enhances adaptability in diverse conditions, from mining operations to urban development, ensuring long-term durability.
The introduction of the SupUTS self-drilling anchor system aligns with global trends in infrastructure safety and sustainability. As urbanization accelerates, the demand for reliable ground anchor bolts increases, particularly in earthquake-prone or coastal regions. This product contributes to reduced construction timelines and enhanced safety standards, supporting initiatives like the UN's Sustainable Development Goals. The drill-and-grout bolt technology offered by SupAnchor helps mitigate risks in tunneling and mining, promoting economic growth through resilient infrastructure.
SupAnchor's leadership in the self-drilling anchor bolt market is backed by extensive R&D, ISO certifications, and successful global projects. The company's collaborative approach with engineers and contractors ensures that products like the SupUTS series meet international standards. By focusing on professional design and innovative solutions, SupAnchor reinforces its position as a trusted partner in geotechnical engineering, driving advancements that benefit communities worldwide.
